Digital Mixer PreSonus StudioLive 64S

Tech Specs

• Type:Digital Mixer
• Channels:64 channels, 76 mix channels
• Inputs – Mic Preamps:32 x XLR-1/4″ combo (mic/line)
• Phantom Power:Switchable per channel
• Inputs – Line:1 x Dual RCA Stereo (tape), 4 x 1/4″ (2 x stereo aux in)
• Outputs – Main:2 x XLR (main out), 1 x XLR (mono/center), 2 x 1/4″ (monitor)
• Outputs – Other:16 x XLR (mix out), 1 x Dual RCA Stereo (tape)
• Outputs – Digital:1 x XLR (AES/EBU)
• Busses/Groups:32 x FlexMix Buses (aux, subgroup, matrix), 43 total mix buses, 24 x DCA groups
• Talkback:1 x XLR (phantom power)
• Data I/O:1 x Locking Ethernet (AVB audio network), 1 x RJ45 (network control)
• USB:1 x Type B (64 x 64)
• Computer Connectivity:USB 2.0
• Bluetooth:v4.1
• Headphones:1 x 1/4″
• Faders:33 x Touch-sensitive motorized faders
• A/D Resolution:24-bit/48kHz
• Effects:FLEX FX Multi-effects processor, 8 x effects slots, 8 x effects buses
• Signal Processing:Fat Channel plug-ins, 10 x EQs, 10 x Compressors
• Transport Controls:Yes
• DAW Control:Advanced Studio One, MCU Logic emulation, HUI Pro Tools emulation
• Screen:7″ Touchscreen
• Storage:SD card recorder (34 track)
• Software:Studio One Artist, UC Surface (Mac, Windows, Android, iPad), QMix-UC App (iOS, Android), Presonus Capture
• Power Source:Standard IEC AC cable
• Height:6.51″
• Depth:22.97″
• Width:32.37″
• Weight:37.2 lbs.
